Brand
Esgaming
Title
ESGAMING TRUE RATE 650W PSU 80 PLUS
Wattage
650W
Efficiency Certification
80 Plus Bronze / Cybenetics Bronze; Premium Modular Variants
Form Factor
Standard ATX, 160 × 150 × 86mm
Cooling
120mm Auto-Thermally Controlled Hydraulic / Fluid Dynamic Bearing (FDB) Fan
Internal Architecture
DC-to-DC Voltage Regulator Design
Input Voltage
115V / 230V Manual Mechanical Toggle Switch
Cable Configuration
Non-Modular, Pre-Attached Flat Black Cables
Motherboard Connector
24-Pin Main Power × 1 (550mm)
CPU Connector
4+4-Pin (8-Pin) EPS 12V × 1 (610mm)
GPU Connector
PCIe 6+2-Pin × 2 via Single Daisy-Chained Cable
Peripheral Connectors
SATA × 4, PATA (Molex) × 4, FDD × 1
Protection Features
OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection)
